Hydraulic Punch Press for Solar Water Heater Tank Production Line

Basic Info.

Model NO.	inner tank production line
Power Source	Hydraulic Pressure
Precision	High Precision
Certification	GS, CE, ISO 9001
Condition	New
Throat Depth	1250/1500/2000mm
Mould	Avaliable in Multi-Head Mould
Transport Package	Without Package
Trademark	Getweld
Origin	China
Production Capacity	100 Pieces/Year

Product Description

hydraulic punch press for solar water heater tank line

Product Parameters of 16TON-deep throat pressNominal pressure: 160KnSlide stroke: 70mmNumber of stroke: 120Times/min.Max. shut height: 220mmRegulation variable of shut height: 45mmThroat depth: 500mmThickness of bottom plate: 50mmBottom dimension of stroke Front-back: 180mm Left-right: 200mmDimension of mold shaft hole Dia. 40mm, Depth: 30mmMotor power: 2.2Kw

Product Parameters Of Turret Punching Press
Rated press: 250KnDistance from slider to bottom dead centerat Nominal force: 5.5mmSlider stroke: 80mmNumber of stroke 110times/min.Max. die mounting height: 180mmDie mounting adjustment: 70mmDistance from slider center to machine body 1250mmPower: 2.2KwWorking station: 6, 8, 12, 16
Characteristic Of Solar Water Heater Non-Welding Tank
Beautiful,firm,weldless joint, no rust, no water leakage.
Production Process Of Inner tank
SS /GI Sheet-Shearing-punching-rolling-straight seam processing(bending,manual gluing,lapping)-edge flanging-Stiffening-gluing of end cover-sealing -leakage test
Production Process Of Outer tank
SS /GI Sheet-Shearing-punching-rolling-straight seam processing(bending,manual gluing,lapping)-edge flanging-Stiffening-gluing of end cover-sealing
Abou us
GetWeld are devoting ourselves in designing and supplying water heater production line. With professional team, we focus on full innovation solutions based on continuously enhanced technology, not just supply separate and conventional machines, but concentrating on follow-up project automation upgrading, we offer continuous and prospective project proposal. Keeping on site production supervision and phased acceptance can make sure of perfect product quality and reliable machine performance. Before machines are dispatched, equipment system integration and successful trial running on line is our advantage. And professional commissioning and training is one of work.
Our Service
* One year free warranty. * Follow-up project automation upgrading. * Technical support.* Be customized according to client's requirments.
FAQ
Q: Can your machine be customized ?
A: Yes, we are a professional manufacturer specialized in automatic welding equipment more than 25 years, we have a strong design & technical team, we can design and manufacture as your requirements. Q: How to get an accurate quotation ?
A: Please provide us the detail of the workpiece such as drawings or daily out putQ: What's the shipping cost from China to your country ?
A: We can send machine to your port by sea . Customers specify freight forwarders or negotiable shipping methods
Q: Payment terms, MOQ, warranty, FOB...A: Payment terms: 30% down payment against order Minimum order quantity: 1 setDelivery time: 2-4 months after receipt of formal order Warranty: 12 months following delivery. We offer online service 24 hours all day long, Skype, Email etc. You can contact us any time.Send your message to this supplier
